210mm Aluminum Filled Nylon Battery Tray Mounting Bracket by SLS 3D Printing
|
Product Details:
|
210mm Aluminum Filled Nylon Battery Tray Mounting Bracket by SLS 3D Printing
Description| Material: | PA12 With Aluminum Filler | Layer Thickness: | 0.10 Mm |
|---|---|---|---|
| Build Size: | 210 X 160 X 120 Mm | Dimensional Tolerance: | ±0.12 Mm |
| Flexural Modulus: | 3200 MPa | Density: | 1.35 G/cm³ |
| Highlight: | Aluminum Filled Nylon Bracket,Automotive Battery Tray Bracket,High Rigidity 3D Print |
||
Battery tray brackets must carry load, resist vibration, and hold torque at insert points. This 210mm bracket is printed in aluminum filled PA12, which lifts stiffness and thermal conductivity compared with plain nylon, making it suitable for pack mock-ups and jig work as well as fitment checks.
- Aluminum filler increases stiffness and heat dissipation
- Load path printed as one continuous part without joints
- Heat-set inserts provide repeatable bolt torque for assembly trials
- Rib layout and wall thickness optimized per load case
- Vibration and fitment trial ready for EV and 12V trays
| Process | SLS 3D printing |
|---|---|
| Material | PA12 + aluminum filler |
| Build Envelope | 210 × 160 × 120 mm |
| Tolerance | ± 0.12 mm |
| Flexural Modulus | 3200 MPa |
| Density | 1.35 g/cm³ |
| Insert Types | M4 to M8 heat-set inserts |
| Lead Time | 4–6 working days |
Customization covers tray footprint, hold-down strap slots, ground stud position, and mounting hole pattern. Our engineers review the load case and suggest ribbing before printing so the prototype can be torque tested without cracking.
Send your tray drawing and bolt pattern — we review load paths and reply with a quotation within one working day.
-
