Nickel Plated Automotive Connector Terminal with ±0.05 mm Pin Tolerance for Reel Taping Assembly
|
Product Details:
|
Nickel Plated Automotive Connector Terminal with ±0.05 mm Pin Tolerance for Reel Taping Assembly
Description| Material: | Brass H62 / C28000 | Pin Tolerance: | ±0.05 Mm |
|---|---|---|---|
| Current Rating: | Up To 30 A | Contact Resistance: | Below 5 MΩ |
| Plating Thickness: | 3-5 µm Nickel | Manufacturing Process: | CNC Turning With Live Tooling |
| Highlight: | Custom CNC Machined Terminal,Automotive Brass Terminal,Turning H62 Nickel Plated |
||
These connector terminals are turned from H62 brass on CNC lathes with live tooling, holding ±0.05 mm on the contact diameter before nickel plating. Consistent insertion force and contact resistance below 5 mΩ keep harness assembly lines running without crimp rejects, and reel taping lets the parts feed directly into automatic crimping equipment.
- Turned Contact Precision — ±0.05 mm contact diameter for stable insertion and pull-out force.
- Plating You Specify — Nickel 3–5 µm or tin plating with thickness and adhesion reports.
- Low Contact Resistance — Below 5 mΩ after plating, validated by sampling test.
- Reel or Bulk Packing — Reel taping for automatic crimping, poly bags for manual assembly.
- High Output Capacity — Two million pieces per month on multi-spindle turning cells.
| Material | Brass H62 / C28000 |
|---|---|
| Manufacturing Process | CNC turning with live tooling |
| Pin Tolerance | ±0.05 mm |
| Surface Treatment | Nickel or tin plating |
| Current Rating | Up to 30 A |
| Contact Resistance | Below 5 mΩ |
| Application | Wiring harness and ECU connector terminals |
| Certification | ISO 9001:2015, RoHS |
Send a 3D model or 2D drawing and our engineering team returns a machining quotation within 24 hours, together with material and finish recommendations. OEM and ODM are both supported: geometry, tolerance band, thread class, surface treatment and laser marking are all adjusted to your specification, then locked in with a first-article sample before mass production.
Parts are bagged in PE film with shock-proof foam inserts inside export-grade corrugated cartons, keeping machined surfaces free of nicks in transit. Barcode labels, desiccant bags and palletized packing are available on request.
-
