Custom CNC Machined 20CrMnTi Carburized Gear Blank with Turning Hobbing for Automotive Transmission

Gear blanks are turned, bored and hobbed from 20CrMnTi alloy steel on CNC lathes and hobbing machines, holding DIN 7 tooth accuracy with 0.15–0.30 mm grinding stock on the flanks. Carburizing and quenching raises the case to 58–62 HRC while the core stays tough, giving the transmission gear the wear resistance and impact strength it needs after final grinding.

• Cut to Your Gear Data — Module, pressure angle, helix angle and tip diameter machined to your gear drawing.
• Controlled Heat Treatment — Carburizing depth and case hardness verified with micro-hardness traverse.
• Accurate Tooth Form — Gear measuring center checks profile, lead and pitch deviation per lot.
• Grinding Stock Included — 0.15–0.30 mm on flanks so your grinder reaches final DIN 6 accuracy.
• Forging or Bar Stock — Closed die forging available for higher grain flow on loaded gears.

Send a 3D model or 2D drawing and our engineering team returns a machining quotation within 24 hours, together with material and finish recommendations. OEM and ODM are both supported: geometry, tolerance band, thread class, surface treatment and laser marking are all adjusted to your specification, then locked in with a first-article sample before mass production.

Parts are bagged in PE film with shock-proof foam inserts inside export-grade corrugated cartons, keeping machined surfaces free of nicks in transit. Barcode labels, desiccant bags and palletized packing are available on request.
